NovaStar TB60 Taurus Multimedia Player for LED Displays

NovaStar TB60 is a new-generation multimedia player designed for full-color LED displays, integrating media playback and LED sending/control functions into one compact device.

With a loading capacity of up to 2.3 million pixels, 4 Gigabit Ethernet outputs, 4K video decoding, HDMI input/output, Wi-Fi and optional 4G connectivity, the TB60 provides a powerful solution for both synchronous and asynchronous LED display applications.

Content can be published and LED screens managed from a computer, smartphone or tablet, while NovaStar’s cloud-based platform enables remote content publishing, screen control and monitoring over the Internet.

Key Features

• Up to 2,300,000 pixels loading capacity
• 4 × Gigabit Ethernet LED outputs
• Maximum standard screen width: 4096 pixels
• Maximum standard screen height: 4096 pixels
• Ultra-long screen width up to 23,040 pixels
• 4K video decoding
• Quad-core ARM A55 1.8 GHz processor
• 1 GB RAM + 32 GB internal storage
• Supports Synchronous & Asynchronous modes
• 1 × HDMI 1.3 Input
• 1 × HDMI 1.3 Output with HDMI Loop
• Built-in 2.4 GHz Wi-Fi
• Optional 4G communication
• Remote content publishing and screen monitoring
• Multi-screen synchronous playback
• USB playback and storage expansion
• Supports brightness and temperature/humidity sensors
• Ethernet port redundancy supported

The four Gigabit Ethernet outputs operate as primary ports by default, or can be configured as 2 primary + 2 backup ports for applications requiring higher reliability.

Main Specifications

Model: TB60
Series: NovaStar Taurus Series
Product Type: Multimedia Player / LED Sending Player

Loading Capacity: 2,300,000 Pixels
Maximum Width: 4096 Pixels
Maximum Height: 4096 Pixels
Ultra-Long Screen Maximum Width: 23,040 Pixels
Ultra-Long Screen Maximum Height: 4096 Pixels

LED Outputs: 4 × Gigabit Ethernet
HDMI Input: 1 × HDMI 1.3
Maximum HDMI Input: 1920 × 1200 @ 60Hz
HDMI Output: 1 × HDMI 1.3
Maximum HDMI Output: 1920 × 1200 @ 60Hz
HDMI Loop: Supported

Processor: Quad-Core ARM A55 @ 1.8 GHz
Video Decoding: Up to 4K
RAM: 1 GB
Internal Storage: 32 GB

Wi-Fi: 2.4 GHz
4G: Supported with Optional 4G Module
Gigabit Ethernet Control Port: 1
USB: USB 3.0 Type-A + USB Type-B
Sensor Ports: 2
Audio Output: 3.5 mm

Operating Modes: Synchronous / Asynchronous
Operating System: Android 11

Input Power: 100–240V~, 50/60Hz
Maximum Power Consumption: 18 W
Operating Temperature: -20°C to +60°C
Storage Temperature: -40°C to +80°C
IP Rating: IP20

Dimensions: 274.3 × 139.0 × 40.0 mm
Net Weight: 1230.4 g

Powerful 4K Media Playback

The TB60 features a quad-core ARM A55 processor and supports 4K video decoding. Its playback capability supports:

• 1 × 4K video
• 2 × 1080p videos
• 5 × 720p videos
• 6 × 480p videos
• 6 × 360p videos

This makes the TB60 suitable for multimedia-rich commercial LED displays with multiple content windows.

Synchronous & Asynchronous Operation

One of the major advantages of the TB60 is its ability to switch between two operating modes.

Asynchronous Mode
Content stored inside the TB60 is played directly without requiring a computer or external video source to remain connected.

Synchronous Mode
The TB60 uses its HDMI input as the video source and can automatically scale the incoming video to fit the LED screen.

This makes one controller suitable for both digital signage and live video applications.

Remote LED Screen Management

The TB60 allows users to publish content and control LED displays using a computer, smartphone or tablet.

With Internet connectivity, users can remotely:

• Publish and update content
• Control LED displays
• Monitor screen status
• Manage multiple displays
• Schedule and update advertising content

Network connectivity can be provided through wired Ethernet, Wi-Fi or optional 4G, with priority given to Wired Network → Wi-Fi → 4G when multiple connections are available.

Typical Applications

LED Advertising Displays
Ideal for remotely managed indoor and outdoor advertising screens.

LED Poster & Digital Signage
Perfect for standalone LED posters, advertising machines and commercial signage.

Retail & Chain Stores
Centralized content management for LED screens across multiple locations.

Fixed LED Displays
Suitable for shopping malls, hotels, showrooms, corporate displays and commercial installations.

Smart City Applications
Can be used for lamp-post displays, information displays and distributed LED signage networks.

Large & Ultra-Wide LED Displays
The latest TB60 supports ultra-long LED screens with widths up to 23,040 pixels, making it useful for banner-style and highly elongated LED displays.

Why Choose NovaStar TB60?

The TB60 combines an LED sending controller, multimedia player, HDMI input, local storage and remote network management in one device.

For commercial LED displays that need to operate independently without a permanently connected PC, the TB60 provides a practical solution: upload content, schedule playback and manage the screen remotely through the network.

Its 2.3-million-pixel capacity, four Gigabit outputs, 4K decoding and optional 4G connectivity make it particularly suitable for professional digital signage and distributed LED display systems.
