The HDC-EHB150CG is a professional 18Gbps HDBaseT HDMI extender designed to transmit high-definition video/audio, RS-232, and bi-directional IR over a single CAT5e/6 cable—up to 150m (492ft) at 1080p or 120m (394ft) at 4K2K@60Hz 4:4:4.
It supports HDMI loop-out on the transmitter for local display monitoring and features audio extraction on the receiver for L/R stereo output. HDR formats such as HDR10+, Dolby Vision, and HLG are fully supported, ensuring exceptional image quality.
With PoC (Power over Cable) technology, only one power adapter is required for the entire system. Its compact, plug-and-play design makes it ideal for professional AV setups, including conference rooms, control centers, digital signage, and home theaters.
Key Features:
-
✅ HDCP 2.2 / HDCP 1.4 and DVI 1.0 compliant
-
✅ Supports up to 18Gbps video bandwidth
-
✅ Resolution support:
• 4K2K@60Hz 4:4:4 up to 120m (394ft)
• 1080p@60Hz up to 150m (492ft)
-
✅ HDMI loop-out on transmitter for local display
-
✅ Audio extraction to analog stereo output on receiver
-
✅ Supports HDR, HDR10+, Dolby Vision, HLG pass-through
-
✅ Bi-directional IR, RS-232, and CEC pass-through
-
✅ PoC (Power over Cable) – only one power adapter needed
-
✅ Compact design for flexible installation
Applications:
-
Corporate meeting rooms and training centers
-
Home theater installations
-
Control rooms and command centers
-
Digital signage and retail displays
-
Multi-room AV distribution
